CHEMICAL HOSE
Chemical hose Construction:
Tube: Transparent XLPE (cross-linked polyethylene)
Size: 3/4”–4”
Working pressure: 10bar
Lenght: 20m/40m/60m
Weight: 0.67–5.06kg/m
Color: Blue, Green
Reinforcement:High tensile textile cords with/without 4highly flexible steel helix wires
Cover: Green EPDM-Abrasion and ozone resistant
Chemical hose Application:
Designed for in-plant or tank truck use to transfer chemicals and solvents.
Chemical hose Temperature:
-40℃ to + 120℃((-72℉ to +248℉)
Chemical hose Characteristic:
●Handle the chemical/acid
●Heat,weather,abrasion resistant EPDM cover
●Corrugated cover make hose more flexible
Specification:
| PART NUMBER | HOSE SIZES | OD | OPERATING PRESSURE | BURST PRESSURE | BEND RASIUS | WEIGHT | LENGTH PER PCS | |||||||
| ID | DN | MN | INCH | MM | BAR | PSI | BAR | PSI | MM | KGS/M | METER | |||
| SPI-19 | -12 | 19.00 | 3/4” | 31.00 | 10 | 150 | 30 | 450 | 150 | 0.67 | 20/40/60 | |||
| SPI-25 | -16 | 25.40 | 1” | 37.00 | 10 | 150 | 30 | 450 | 200 | .084 | 20/40/60 | |||
| SPI-32 | -20 | 31.80 | 1 1/4” | 45.00 | 10 | 150 | 30 | 450 | 250 | 1.20 | 20/40/60 | |||
| SPI-38 | -24 | 38.10 | 1 1/2” | 52.00 | 10 | 150 | 30 | 450 | 300 | 1.52 | 20/40/60 | |||
| SPI-50 | -32 | 51.00 | 2” | 65.00 | 10 | 150 | 30 | 450 | 350 | 1.96 | 20/40/60 | |||
| SPI-65 | -40 | 63.50 | 2 1/2” | 80.00 | 10 | 150 | 30 | 450 | 400 | 2.95 | 20/40/60 | |||
| SPI-76 | -48 | 76.20 | 3” | 92.00 | 10 | 150 | 30 | 450 | 450 | 3.44 | 20/40/60 | |||
| SPI-100 | -64 | 102.00 | 4” | 120.00 | 10 | 150 | 30 | 450 | 500 | 5.06 | 20/40/60 | |||
Delivery
HYRUBBERS built excellent transportation newt work. The rubber hose could be delivered to clients by sea, by air, by highway transportation, to make sure the clients get the rubber hose in time.
